HDTV/SDTV with HDMI input
SDI output devices : SD-SDI,HD-SDI and 3G-SDI
.
| Power Supply | DC 5V/1A | |
| SDI input | SDI format | SD-SDI HD-SDI 3G-SDI |
| SDI data transfer rates | 270Mb/s 1.485Gb/s 2.97Gb/s | |
| Impedance | 75Ω | |
| SDI input resolutions | 720P/50Hz 720P/60Hz 1080i/50Hz 1080i/60Hz 1080P/24/25/30/50/60Hz Recommended resolutions: 720P@50Hz/60Hz or 1080P@50Hz/60Hz |
|
| HDMI output | HDMI output resolutions | 720P/50Hz 720P/60Hz 1080i/50Hz 1080i/60Hz 1080P/24/25/30/50/60Hz |
| Dimensions | 104x59x22mm(L*W*Hmm) | |
| Weight | 72g | |
| Working Temperature | 0℃~50℃ | |
