1/4 type 380k pixel EXview HAD CCD
Wide Range Pan/Tilt: 340 degrees Pan / 120 degrees Tilt
High Zoom Ratio AF Lens: 18x Optical + 12x Digital
Excellent Low Light Sensitivity: Minimum illumination less than 1 Lux
Desktop or Ceiling Mount Installation
E:Flip Function (electronic flip): Electronically flips an image upside down so it displays correctly when ceiling mounted
37mm Mount for Optional Conversion Lens
Fully Remote Controllable via RS-232C (VISCA) or RS-422
Auto ICR Function
Auto Focus
Video Output: VBS (pin jack) and Y/C (4 pin MiniDIN)
Alarm Function
AE Spot Setting
Custom Preset Function
| Signal System | PAL/NTSC |
| Image sensor | 1/4 Inch Color CCD |
| Resolution | 480 TVL |
| Video Input | 1.0±0.2Vp_p |
| Rotation speed | Horizontal 0.5°-280°/s; Tilt 0.3°-240°/s |
| S/N | 50dB |
| Illumination | 0.01 Lux |
| Switch methods | D & N |
| AGC | Auto/Manual |
| BLC | Auto/Manual |
| Lens | F=4.1-73.8mm |
| Optical Zoom | 18x |
| Digital Zoom | 12x |
| Rotation angle | 360°continuous pan;Vetical Tilt 0°-91°with auto flip |
| Preset position | 128 |
| Auto Cruise group | 8 groups |
| Alarm Input | 7 channels |
| Alarm Output | 2 channels |
| Communication | RS485 control |
| Baud Rate | 1200bps、2400bps、4800bps、9600bps |
| Input Voltage | 24VAC |
| Power supply | 20W(without heater) /50w (with heater) |
| Temperature | -25°C-70°C(Without heater) /-50°C-70°C(with heater) |
| Housing Size | 6 Inch |
