• Waterproof, dustproof, convenient installation and debugging, comprehensive functions
• Can support double - port cyclic output charging
• High efficiency, high power density and high reliability
• Support multiple payment methods
• Small space occupation
| Model | SSCDC60KW |
| Power supply | DC |
| Maximum output power | 150KW |
| Maximum output current | 63A |
| AC voltage | 380 Va.c.±15% |
| Frequency | 50/60Hz |
| Efficiency | 97% Nominal output power |
| charge mode | Single |
| Installation | Posts / Walls |
| Ethernet | TCP/IP |
| Wireless communications | 3G/4G/WI-FI |
| Protection degree | IP54/IP55 |
| Operating temperature | -20~+65℃ |
| Storage temperature | -40~+70℃ |
| Relative humidity | 5~95% without condensation |
| Noise | No fan mute |
| design | |
| HMI display | 4.3”TFT vandal-proof touch screen |
| Indication of the sate of charge | RGB LED beacons |
| Integration protocol | OCPP 1.6 |
| Shell material | Metal |
| Dimensions | 350*180*1600mm |
| Elevation | 2000m |
| Safer | Over current protection,Earth leakage protection,Lightning protection ,Emergency stop switch,Over temperature protection,over voltage and under pressure protection |
